RIGOL Spectrum Analyzers

From entry level swept spectrum analyzers to advanced real-time analysis RIGOL provides unprecedented value.

Whether you are doing simple signal visualization, integrating wireless technologies into your IoT design, characterizing component performance, preparing for emissions compliance testing or working with complex modulated signals RIGOL has a Spectrum Analyzer to fit your need and budget.

Spectrum Analyzer Configuration Table

Real-time Analyzers


Customers working with complex and rapidly changing signals will appreciate the performance, advanced capabilities, and seamless capture of the UltraReal Real-time Spectrum Analyzer portfolio

Traditional Swept Spectrum Analyzers

Customers who need reliable basic RF visualization tools will appreciate the unprecedented value of our traditional swept spectrum analyzers

Family of Real-time Spectrum Analyzers

Combining the Power of Real-time analysis with a performance swept Spectrum Analyzer

Capture
transient and short duration signals confidently with seemless real-time capture of up to a 40 MHz span and a 7.45 µsec minimum POI.
Identify
errors in power, frequency, and time with seven rich visualization modes
Isolate
signals of interest with powerful Frequency Mask Trigger and Power Trigger capabilities
Analyze
RF Signals and devices that control them with advanced analysis tools for complex signal analysis and pre-compliance testing
Combined with the Power of a High Performance Swept Spectrum Analyzer
  • 3.0 GHz, 3.2 GHz, 4.5 GHz and 6.5 GHz models
  • Available Tracking Generators
  • Down to 1 ms Full Span Sweep
  • Down to 1 Hz RBW
  • Low Noise (DANL to -165 dBm)
  • Low Phase Noise (-108 dBc/hz)

Network Analysis

Spectrum Monitoring

EMI Pre-Compliance

UltraReal Portfolio

RSA5000 Spectrum Analyzer

  • 3.2 GHz and 6.5 GHz Models
  • DANL to -165 dBm
  • RBW 1 Hz
  • Real-time Bandwidth 25 MHz
    (40 MHz opt)
  • 7.45 µs 100% POI
  • 10.1" Touch Display

Models & Pricing  Introduction Video

RSA3000 Spectrum Analyzer

  • 1.5 GHz, 3.0 GHz and 4.5 GHz Models
  • DANL to -161 dBm
  • RBW 1 Hz
  • Real-time Bandwith 10 MHz
    (40 MHz opt)
  • 7.45-9.3 µs 100% POI
  • 10.1" Touch Display

Models & Pricing  Introduction Video

EMI Analysis Mode

RIGOL's EMI Measurement Application provides a complete EMI Pre-Compliance Solution allowing engineers to measure, compare, analyze, and report on EMI issues throughout their design process.

Learn More

VSA Analysis Mode

RIGOL's Vector Signal Analysis provides ability to demodulate and analyze complex modulation signals. View constellation diagrams, spectrum, time, errors, and symbols to speed debug of these complex signals on the RSA5000. Conduct similar analysis on ASK and FSK signals with the RSA3000E Series.

Learn More

RIGOL's VNA Mode

Use the new N models to conduct S Parameter calculations for S11 and S21 as well as Distance To Fault measurements. Analyze group delay, Smith, polar, VSWR, and more characteristics with the included VNA functions.

Learn More

RIGOL Swept Spectrum Analyzers

Powerful Visualization and Analysis Tools at an Economical Price

Our DSA series Spectrum Analyzers are proven performers for a wide range of RF and EMI applications

  • Unmatched price performance from 500 MHz to 7.5 GHz
  • DANL to -161 dBm
  • 10 Hz RBW on most models
  • Integrated Pre-Amp
  • Advanced Analysis Capabilities
    • EMI Filters/Quasi Peak Detectors
    • Advanced Measurements
    • VSWR Measurements

Swept Spectrum Portfolio

DSA700 Spectrum Analyzers

  • 500 MHz and 1 GHz Models
  • DANL to -130 dBm
  • RBW 100 Hz
  • 8" Display

Models & Pricing

DSA815 Spectrum Analyzers

  • 1.5 GHz Models
  • DANL to -155 dBm
  • RBW 10 Hz
  • Tracking Generator Option
  • 8" Display

Models & Pricing

DSA832/875 Spectrum Analyzers

  • 3.2 GHz and 7.5 GHz Models
  • DANL to -161 dBm
  • RBW 10 Hz
  • Tracking Generator Option
  • 8" Display

Models & Pricing

RIGOL Spectrum Analyzer Portfolio

Product Series Frequency Range Real Time Analysis Bandwidth Minimum DANL RBW Display RIGOL vs. Competition
3.2 GHz - 6.5 GHz
25 MHz (40 MHz opt)
-165 dBm
1 Hz
10.1" Touch
 Compare
1.5 GHz - 4.5 GHz
10-40 MHz
-161 dBm
1 Hz
10.1" Touch
 Compare
1.5 GHz - 7.5 GHz
N/A
-161 dBm
10 Hz
8" SVGA
 Compare
500 MHz - 1 GHz
N/A
-130 dBm
100 Hz
8" SVGA
